Continuous Activated Carbon Carbonization Furnace

Dingli smokeless activated carbon continuous carbonization furnace is a new type of high-efficiency, energy-saving and environmentally friendly carbonization equipment. It can be applied to a variety of materials, and one machine can be used for multiple purposes. Activated carbon carbonization furnace (carbonization machine) is a device that decomposes coconut shell by heat to produce high carbon content materials under the condition of isolating air or introducing trace gas.

Finished Charcoal Powder

Applicable Materials

The equipment uses sawdust, shavings, wood scraps, branches, rice husks, peanut shells, sugar cane, cotton stalks, corn stalks, wheat straw, rice straw and other crops in the north and south are used as raw materials. Using our new carbonization technology, ideal carbon powder can be obtained, or the carbon residue left when making charcoal briquettes can be obtained. It can be crushed, milled and stirred, and pressed into shape.

Applicable Materials.jpg

Equipment Warrior


Dingli smokeless activated carbon continuous carbonization furnace is a new type of high-efficiency, energy-saving and environmentally friendly carbonization equipment. It can be applied to a variety of materials, and one machine can be used for multiple purposes.

Parameters

Model Capacity(kg/h) Drum Diameter(m) Drum Length(m) Size(m)L*W*H Output Ratio
DLHH2210 80-100 2.2 10 11.1*2.6*3.0 2.2-2.6:1
DLHH2510 120-150 2.5 10 11.3*3.0*3.5 2.2-2.6:1
DLHH2810 170-200 2.8 10 11.5*3.4*4.0 2.1-2.5:1
DLHH2815 250-300 2.8 15 16.5*3.4*4.0 2.1-2.5:1
DLHH3215 320-400 3.2 15 16.6*3.8*4.4 2.1-2.5:1
DLHH3615 430-540 3.6 15 16.6*4.2*4.8 2.1-2.5:1

1. The material is dynamically pyrolyzed, heated evenly, and there is no phenomenon of entrainment. The product has excellent indicators such as high carbon content, low ash content, and low volatile content.

2. The pyrolysis temperature is much lower than that of traditional earthen kilns. The special heat conduction and heat carrier internal circulation system minimizes the energy consumption of the carbonization machine, which is about 15% of its own energy. The vast majority of energy is preserved in the form of carbon, gas, and oil.

3. The indirect heating method is used to transfer heat, so that the temperature of the exhaust gas in the interlayer of the furnace is about 300 °C, which can be used for raw material drying or heat exchanger for reuse and recycling.

4. The amount of tail gas emitted by the carbonization process is greatly reduced compared to the amount emitted by the incineration method, only 1/10. There are huge advantages in terms of environmental protection.
